Lens DSL398

DSL203A Wide Angle Security Lens

Key Features :

• Designed for multi-megapixel resolution sensors
• Full field of view of up to 140°
• High brightness, F/2.6 aperture
• All glass design provides environmental stability

Applications :

• Security and surveillance
• Automotive rear view cameras

The DSL202 lens is a multi-element glass lens optimized for imager sizes up to 1/3" format and HD resolution. The all glass, all metal construction enables good thermal stability. The DSL202 is also environmentally ruggedized

Key Features:

•  176° wide angle FoV
•  Good low light performance: F/2.0 relative aperture
•  All glass design to optimize thermal stability

Applications:

•  Automotive Rear View Cameras
•  Security and Surveillance
•  Computer Vision

Compatible with GoPro HERO1, HERO2 , HERO3, HERO3+ and HERO4 ®.

Maintains large field properties for your camera and HD quality.

It will bring you images with very low distortion and optimum color resolution.

The prefered optical of drone owners.

Choose your filter : we can offer a version for infrared observations.

The DSL180 lens is a Tailored DistortionTM, miniature SuperFisheyeTM lens designed with a field of view of up to 200 degrees on 1/5” to 1/2.8” format imagers with HD resolution. Special design techniques and hybrid design form are used to achieve increased magnification (angular resolution) off axis compared to a standard fisheye lens.

NIR versions: No IR cut filter

Key Features :

• Wide field of view : 126 deg HFOV on 1/3” imager
• Excellent low light performance: F/2.0 aperture
• All glass elements providing environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h=f*θ where f is the focal length).

Ultra-low F/# for superb low-light imaging in Automotive, Autonomous and Security related applications, 4K, Low-Ghost design provides excellent image quality.

• Hybrid lens for excellent image and distortion characteristics
• HDR-Optimized for Low flare and ghost
• High (4K) resolution and extremely low F/# for bright, sharp images.

The DSL977 is an all-glass lens designed for 1MP HDR imagers. Special optical design, coating and process techniques are applied to achieve the high resolution, low relative aperture eliminating lens ghosting (120dB) and minimize flare and stray light.

Key Features :

• NoGhost, low stray light for HDR sensors
• Low relative aperture F/1.8
• Face Sealed to IP6K9K
• Compact size

Compatibility GoPro® HERO 1 HERO 2 HERO 3, HERO and HERO 4®

• This objective is part of a new optical generation.
• There is no better in technology.
• This optical record with a field of view of 90 °. Without cut NIR

The DSL901 is a multi-element glass lens designed for 2/3” imagers with up to 1.3MP resolution. The compact form factor of the DSL901 relative to the large imager format size makes this lens ideal for size constrained machine vision applications.

*NIR = without IR cut filter

DSL311A 650F2.8

Key Features :

• 151° FOV
• F/2.8
• 22mm TTL

Applications:

• Security/Surveillance
• Automotive Rear-view
• Sports and Wearable Cameras

Key Features :

•  F/1.7 for enhanced low light sensitivity
•  All glass to optimize thermal stability
•  Low stray light for HDR sensors

Applications :

•  Automotive Forward Machine Vision (Sensing)
•  Automotive Mirror Replacement (CMS/eMirror)
•  Security Cameras
•  Computer Vision

DSL217C-670-F1.8

•  Maximum field of view (FOV): 185o
•  F/1.8 aperture for low-light performance
•  Hybrid glass-plastic design
•  Suitable for megapixel resolution sensors

DSL165 is a high-performance lens with ultra-low F/# for superior low light imaging in Automotive, Autonomous and Security applications. Low-Ghost HDR and 4K design provide excellent image quality. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.
