Lens DSL239

The DSL212 is a miniature wide-angle all-glass lens with Tailored Distortion. This lens was optimized for 1/3” format sensors with up to HD resolution. The Tailored Distortion wide field of view and all glass construction make it ideal for outdoor applications which depend on off axis angular resolution.

Available in NIR versions: No IR cut filter

Key Features :

•  F/1.7 for enhanced low light sensitivity
•  All glass to optimize thermal stability
•  Low stray light for HDR sensors

Applications :

•  Automotive Forward Machine Vision (Sensing)
•  Automotive Mirror Replacement (CMS/eMirror)
•  Security Cameras
•  Computer Vision

The DSL949 is a hybrid lens designed for 1/3” imagers withup to 5MP resolution. Special design techniques enable the DSL949 to achieve a wider than normal field of view with very low distortion in a small form factor.

Key Features :

• Wide field of view: 75°HFOV on 1/4” imager
• All glass elements provides environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h = f*θ where f is the focal length)

Applications :

• Security and Surveillance

The DSL935 lens is a multiple element glass lens optimized for 1/1.8” format imagers with up to 5MP resolution. The small form factor makes this lens ideal for high performance handheld cameras.

DSL419B-650-F2.0

Key Features :

•  SuperFisheye FOV: 180°
•  All-Glass Design•  Good low light performance: F/2.0 aperture
•  Compact size

Applications :

• Security and Surveillance
• Drones
• Immersive Imaging
• Video Communication
• Consumer Devices and IoT

Key Features :

•  All glass construction to optimize thermal stability
•  Low F/# for improved low light performance
•  Compact size

Applications :

•  Security and Surveillance
•  Drone cameras
•  Immersive Imaging

The DSL936 is a multi-element glass lens optimized for 1⁄2” imagers with up to 5MP resolution. The DSL936 is Day/Night optimized for improved performance in the near infrared making this lens ideal for applications which require active illumination at 850nm or 940nm.

DSL208A-650-F4.0 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.

Available in NIR versions: No IR cut filter

DSL261

Key Features :

•. Ultra-wide FOV: 160°
•  Sunex NoGhostTM HDR-Optimized design
•  All-Glass Design for thermal stability
•  Good low light performance: F/2.8 aperture
•  Compact size

Applications :

•  Security and Surveillance cameras
•  Drone cameras
•  Immersive Imaging cameras

The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with up to 1/2” format size. The SuperFisheyeTM design provides a FOV of 190 ̊ at design image circle of 4.3mm. The low F-number, compact size and thermal stability make this lens ideal for security and other high-quality indoor/outdoor imaging applications.

Key Features:

•  176° wide angle FoV
•  Good low light performance: F/2.0 relative aperture
•  All glass design to optimize thermal stability

Applications:

•  Automotive Rear View Cameras
•  Security and Surveillance
•  Computer Vision

DSL355A-650-F2.8

Key Features :

• Miniature Wide Angle Lens
• Compact size
• High image quality
• Low distortion

Applications :

• Security / Surveillance
• Telecommunications / Video-Conferencing
• Action Cameras
